iCANnet Cable

iCANnetâ„¢ Network Cable

iCANnetâ„¢ Network Cable is specifically designed to connect between each device on an iLight control system. The cable consists of 2 x 18 AWG tinned copper wire with PE Insulation (Power pair) and 2 x 22 AWG screened tinned copper wire with PE Insulation (data pair). There is also a tinned copper drain wire in contact with the aluminium foil screen. The cable is sheathed overall in LSZH.

Icannet Cable 600px

Features

  • Conductor: 18 AWG, tinned copper
  • Insulation: Polyethylene
  • Colour code: Red & black
  • Conductor: 22 AWG, tinned copper
  • Insulation: Polyethylene
  • Screen: Aluminium foil
  • Drain wire: Tinned copper
  • Colour code: White & blue
  • Jacket: Low smoke halogen free
  • Colour: Blue
  • Overall diameter: 6.35mm (nominal)
  • Cable drum size: 300m
  • Drum weight: 19.5Kg
  • CE compliant to all relevant standards
  • Designed and manufactured to ISO9001:2015 standards
